Nov 10, 2020 / 11:57

Germany mega machine TBM ready for Hanoi's subway drilling

The machine was manufactured by German firm Herrenkecht based on the Tunnel Boring Machine (TBM) method.

Part of a boring machine made by Germany has arrived in Hanoi to build the underground section for the city's second metro line, Nhon-Hanoi Railway Station, according to the Hanoi Metropolitan Railway Management Board (MRB).

The MRB said on November 9 that the components of the machine had arrived at Hoang Dieu port in northern Hai Phong city, about a two-hour drive east of Hanoi, in late October.

 The machine was manufactured by German firm Herrenkecht based on the Tunnel Boring Machine method

It is estimated that the assembly of the excavator would take two months, so drilling on the route of the Nhon-Hanoi train station can begin in January 2021.

The machine was manufactured by German firm Herrenkecht based on the TBM method. It stretches more than 100 meters, weighs over 850 tons and has a rotating cutting wheel with a diameter of 6.55 meters. The machine is designed to drill 10 meters of tunnel per day.

According to MRB, the complex apparatus includes a cutting rotor, propulsion cylinder and waste (including soil and rocks) transportation system.

To take the components down to S9, the first of the four underground stations on the Nhon – Hanoi Railway Station route along Kim Ma street in Ba Dinh district, the MRB will employ cranes with a loading capacity of 500 tons to move them one by one.

All the components will be assembled on the site at S9 station to commence work on the four-kilometer underground section of the route, named Metro Line No. 3 though it is currently only the second in the city to start construction after Cat Linh-Ha Dong.

Hanoi’s second metro line, the Nhon-Hanoi Railway Station route, will run 12.5 kilometers from the Nhon area in the western district of Nam Tu Liem via Kim Ma street to Hanoi Railway Station on Le Duan street.

It will run 8.5 kilometers on elevated tracks through eight stations and the remaining four kilometers underground.

The metro line on October 20 received its first train from France and begin operations in April 2021 on the elevated track, which is now 99.5% complete. The underground track is scheduled to begin operations in 2023.

The Nhon-Hanoi Railway Station metro line has a total investment of VND36 trillion (US$1.56 billion), sourced mainly from official development assistance (ODA) loans.

Hanoi’s first metro line, connecting Cat Linh station in downtown Dong Da district to the Yen Nghia station in Ha Dong district, is said to be 99% complete, having missed its deadline several times.
